SmartOffice PS286 Plus

  • Scan Speeds up to 25 ppm / 50 ipm in Grayscale Mode
  • Documents and Rigid Cards
  • Creates Searchable PDFs
  • Single Touch Scanning to 9 Destinations



Reliable Paper Handling
A redesigned 50 page Automatic Document Feeder with a 1500 page per day duty enable the SmartOffice PS286 Plus to be used in any application requiring frequent document and rigid card scanning.

Versatile Paper Handling Ability
The SmartOffice PS286 Plus is designed to scan business documents up to 14” long and rigid cards, such as ID cards and drivers licenses, up to 1.2mm thick, without operator adjustments. Mixed

Easy to Use
Single Touch buttons automate up to 9 different scanning jobs including: scan to searchable PDF, save to folder on your network or your computer, scan to email, scan to an application, and scan to printer

Compatible with most imaging applications
Industry standard TWAIN and WIA drivers combined with TIF, JPG, PDF and Microsoft Office file formats ensure compatibility with thousands of scanning and imaging programs. ABBYY FineReader Sprint is included to easily create and manage searchable PDFs at the touch of a button. Built in image processing insures the highest image quality, reduces rescans and increases OCR accuracy.



Features

The SmartOffice PS286 Plus has following features:

● Auto Threshold
Automatically thresholds the current image into a binary black and white image
.
● Auto Rotate
Automatically rotates document based on the contents of the document.
● Auto Crop & Deskew
Automatically straightens and crops image to the documents actual size.



● Color Dropout
Removes red, green or blue color when scanning forms

.



● Blank Page Removal
Automatically removes blank pages without manual editing.

Specification



Type Automatic Document Feeder (ADF)
Image Sensor CIS x 2 (duplex)
Optical Resolution 600 dpi
Hardware Resolution 600 x 600 dpi
ADF Capacity 1. 50 sheets (A4/Letter, 70 g/㎡ or 18 lb.), Max. thickness under 5mm (0.2″).
2. 20 sheets (Business Cards)
3. Plastic Card, Max. thickness under 1.2 mm.
Note: Maximum ADF capacity varies, depending upon paper weight.
Scanning Speed ( ADF ) 25 ppm/50 ipm (200 dpi, grayscale mode, A4 Portrait)
25 ppm/50 ipm (200 dpi, B&W mode, A4 Portrait)
9 ppm/9 ipm (200 dpi, color mode, A4 Portrait)
Note: Results may vary depending upon your scanning application, computer processor and system memory.
Scanning Area (W x L) Max: 216 x 1270 mm (8.5” x 50”)
Min: 13.2 x 13.2 mm (0.52” x 0.52”)
Scan: Name Card, A5, Quarto, Letter, A4, Folio (F4), Legal
Acceptable Paper Sizes (W x L) Max: 220 x 1300 mm (8.66” x 51”)
Min: 50.8 x 50.8 mm (2” x 2”)
Acceptable Paper Weight (Thickness) 50 to 105 g/㎡ (14 to 28 Lbs)
Daily Duty Scan ( Sheets ) 1.500
Roller Lifetime (Scans) 100.000
Pad Lifetime (Scans) 20.000
Action Button Scan, PDF, OCR, File, E-Mail, Copy, BCR, FTP. All Customizable.
Power Supply 24Vdc/0.75 A
Interface USB 2.0
Net Weight 1.66 Kgs (3.66 Lbs)
Dimensions (W x D x H) 263 x 127.5 x 148 mm (10.36” x 5.02” x 5.83”)
Protocol TWAIN Compliant
OS Windows XP, Vista, 7, 8, 10
Mac Os 10.8, 10.9, 10.10, 10.11
Hardware Requirements Pentium IV 2.0 GHz processor (Pentium IV 3.0 GHz processor recommended)
CD-ROM Driver
One available USB Port (USB 2.0 recommended)
1GB RAM or higher recommended
800 MB free HDD space (1 GB or larger recommended)
High Color graphic card (VGA or higher)



Product Weight Specification

Net Weight 1,66 Kg
Bruto Weight 5 Kg
Product Dimensions (W x D x H) 26,3 x 12,7 x 14,8 cm
Box Dimensions (W x D x H) 37 x 25 x 30 cm

Downloads

Driver Scanner :
 SmartOffice PS286 Plus Driver for Windows XP-11
Size : 110 mB (updated 10 March 2021)
SmartOffice PS286 Plus Driver for Mac 10.12-12.x
Size : 36 mB (updated 20 July 2021)
Leaflet :
 SmartOffice PS286 Plus Leaflet
Size : 0.50 mB (updated 4 January 2022)
User Guide:
 SmartOffice PS286 Plus User Guide for windows
Size : 1.32 mB (updated 6 Oktober 2021)
 SmartOffice PS286 Plus User Guide for mac
Size : 3.22 mB (updated 3 Sept 2020)
